320x10mm 5500cd 96x96 SST-F6 4K Video Wall Controller

Shenzhen Shervin Technology Co., Ltd

320x10mm 5500cd 96x96 SST-F6 4K Video Wall Controller

  • 1
  • 2

Brand Name : shervin

Model Number : SST-F6

Certification : CCC.CE.ROHS

Place of Origin : China

MOQ : 1 square meter

Price : 300-800 usd/sets

Payment Terms : L/C, D/A, D/P, Western Union, Western Union

Supply Ability : 5000square meter per month

Delivery Time : within 5days after your payment

Packaging Details : wooden box and Pearl cotton inside

Power Supply : Meanwell power supply

Cabinet size : 640x640mm

Display Function : video

Module size : 320x10mm

Pixel Pitch : 10mm

color : full color

life usage : 10 years

scan way : 1/4

Contact Now

full color water-proof cabinet 4K Video Wall Processor for super marekt usage 3 years warranty

1, High -contrast: Adopting independent design of front mask to avoid hydrops & dust stratification:optimizing sawtooth surface to enhance diffuse reflection and improve the contrast of LED display.

2, wide viewing angle:Horizontal viewing angle can be up to120 degree.It is still colorful from any angle within 120 degree,with no color patches.

3, High gray scale: Adopting 16 bit gray scale processing technology to restore the natural image.Using S-PWM driving technology to improve gray grade,meet the 16 bit high gray display requirements under low brightness.

2. point by point calibration: adopting the point by point calibration technology of brightness and chrominance to ensure the uniformity of led display brightness and color.

Stability and Reliability

1. High Protection: Adopting three proofing ,IP level reaches IP65-IP68 ,works well in severe environment.

2. Good heat dissipation:Detaching the power heat and driving heat to reduce the harmful effect to the LEDs from power heat.Mounting AC fan inclined with huge air output to increase the cooling uniformity.

3. High reliability: adopting static scanning and modular design technology,to realize high stability and reliability.

4. Easy to install and Maintain: Quick positioning and installation,front ,back and single point maintenance are optional.

the detailed specification of outdoor led display as follows.

LED Cabinet Cabinet Size 960MM X960MM
S Resolution 96pixels *96pixels
Cabinets Material iron cabinet
LED Display Pixel Density 10000pixels/sq.m
Drive IC ICN
Power Supply Series connection
Brightness 5500cd/sqm
Display Color 16.7million
Viewing Angle 110°(Horizontal),50°(Vertical)
Best Viewing Distance 10m~100m
Max Power Consumption 750 w/sq.m
Average Power Consumption 450 w/sq.m
Weight 35kgs/sq.m
Refresh Rate 1920hz
Input Voltage AC220V/50H or AC110V/60H
Output Voltage DC5V,40A
Grey Scale Levels 16bit
Display Colors R(1024) x G(1024) x B(1024)
MTBF 10,000 hours
Life-span 100,000 hours
Protection Level IP65
Failure percentage of leds less than 0.0003
Working Temperature -25~65
Drive Mode 1/4 scan
Working Humidity 10%~99%

Specification Drive method module size pixel Pixel composition Point density Cabinet size / length and width
P3.91die cast aluminum(SMD) 1/8 scan 250*250mm 64*64 1R1G1B 65410 500*1000MM
P3.91iron cabinet(SMD) 1/8 scan 250*250mm 64*64 1R1G1B 65410 1000*1000MM
P4(SMD)die cast aluminum 1/8 scan 256*128MM 64*32 1R1G1B 62500 512*512MM
P4(SMD) 1/8 scan 256*128MM 64*32 1R1G1B 62500 768*512MM
P4.81die cast aluminum(SMD) 1/13scan 250*250mm 52*52 1R1G1B 43222 500*1000MM
P5(SMD) 1/8 scan 320*160MM 32*32 1R1G1B 40000 960*960MM
P5(SMD)die cast alumiunm 1/8 scan 320*160MM 64*32 1R1G1B 40000 640*640MM
P5.95(SMD) die cast aluminum 1/7 scan 250*250mm 42*42 1R1G1B 28246 500*1000MM
P6(SMD) 1/8 scan 192*192MM 32*32 1R1G1B 27778 960*960MM
P6(SMD)die cast aluminum 1/8 scan 192*192MM 32*32 1R1G1B 27778 576*576MM
P6.67(SMD)die cast alumium 1/8 scan 320*160MM 48*24 1R1G1B 22478 640*640MM
P8(SMD) 1/4 scan 256mm*128mm 32*16 1R1G1B 15625 1024mm*768mm
P8(SMD)die cast aluminum cabinet 1/4 scan 320mm*160mm 40*20 1R1G1B 15625 640mm*640mm
P10(DIP) 1/4 scan 160mm*160mm 16*16 1R1G1B 10000 960mm*960mm
P10(SMD) 1/4 scan 320mm*160mm 32*16 1R1G1B 10000 960mm*960mm
P10(SMD) 1/2 scan 320mm*160mm 32*16 1R1G1B 10000 960mm*960mm
P10(SMD)die cast aluminum 1/4 scan 320mm*160mm 32*16 1R1G1B 10000 640mm*640mm
P16(DIP) Static full color 256mm*256mm 16*16 1R1G1B 3906 1024mm*1024mm
P20(DIP) Static full color 320mm*160mm 16*8 1R1G1B 2500 1280mm*960mm

Stability and Reliability

1. High Protection: Adopting three proofing ,IP level reaches IP65-IP68 ,works well in severe environment.

2. Good heat dissipation:Detaching the power heat and driving heat to reduce the harmful effect to the LEDs from power heat.Mounting AC fan inclined with huge air output to increase the cooling uniformity.

3. High reliability: adopting static scanning and modular design technology,to realize high stability and reliability.

4. Easy to install and Maintain: Quick positioning and installation,front ,back and single point maintenance are optional.

320x10mm 5500cd 96x96 SST-F6 4K Video Wall Controller

320x10mm 5500cd 96x96 SST-F6 4K Video Wall Controller
